| Product Diagram | Product Model | Max. Permissible Contact Current | Contact Form | Egress Form | Package Form | Coil Type | Overall Dimension (mm) | Foot Position Diagram |
|---|---|---|---|---|---|---|---|---|
| MAA | 35A | 1A | QC | Wash tightDust Protected | Monostable | 23*15.5*25 | ||
| MAB | 70A | 1A | QC | Wash tightDust Protected | Monostable | 26*26*25 | ||
| MAC | 25A | 1C,1C*2 | PCB | SealedDust Protected | Monostable | 14*7.2*13.514*15.4*13.5 | ||
| MAH | 2*20A,40A,60A | 1A,1B,1C,1U | QC | SealedDust Protected | Monostable | 27.8*27.8*25.1 | ||
| MAH3 | 2*20A,40A,60A | 1A,1B,1C,1U | QC | SealedDust Protected | Monostable | 26*26*25 | ||
| MAR | 35A | 1A,1C | QC | SealedDust Protected | / | 26*26*25 | ||
| MAS | 30A | 1A,1C | QC | SealedDust Protected | Monostable | 22.5*15*25 | ||
| MPA | 10A | 1A,1B,1C | PCB | Sealing typeAnti welding flux type | Monostable | 18.7*15*15.2 | ||
| MA101 | 40A | 2A | PCB | SealedFlux Proofed | Monostable | 14.5*11.1*16 | ||
| MAD | 20A | 1A,1B,1C | PCB | SealedFlux Proofed | Monostable | 12.25*12.25*13.6 | ||
| ME106 | 32A | 1A | PCB | SealedFlux Proofed | Monostable | 21.5*16*20.6 |
